Product Silica Aerogels
Silica Aerogels
Silica Aerogels
Silica aerogels are a new material composed of silicon dioxide (SiO2) nanostructures made of silica particles tens of nanometers in size, loosely interwoven like a nonwoven fabric, and are the lightest among all solid materials and possess excellent ultra-thermal insulation and non flammability properties.
Download Catalog
Chemical Structure
  • SiO₂ (CAS Number : 7631-86-9)
Physical Properties
Item Unit Specification
Tap density
g/㎤
0.07~0.15
Specific surface area (BET)
㎡/g
500~900
Thermal conductivity
W/mK
0.021~0.036
Characteristics
  • The space occupying 98% of the total volume is filled with air.
  • Silica aerogel is the lightest among inorganic insulation materials, with a specific surface area of less than 0.1g/cm³.
  • A material with a high specific surface area (over 600 m²/g) featuring a porosity of over 90% and pore sizes ranging from 1 to 50 nm.
Applications
  • Electrical and electronics : Thermal insulation sheets and films, etc.
  • Automotive : Battery insulation and lightweight materials, etc.
  • Construction : Waterproof concrete, blankets, insulation boards, etc.
  • Paint industry : Insulating paints, insulating spray coatings, etc.
